Please help for cosmetics - System Profiler, PCI cards


Best Answer HUSABER, 11 April 2014 - 07:50 PM

After 48 hours insomnia cosmetic problem is solved :hysterical: Many thanks on artur-pt........I love this site :thumbsup_anim: :thumbsup_anim: :thumbsup_anim:


Go to the full post


  • Please log in to reply
20 replies to this topic

#1
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

Hello everybody Hackintosher's :thumbsup_anim:

i neeed litlle help for cosmetics my DSDT..System Profile don't show any PCI Card :wallbash:

And me can't understand how to try on DSDT,every time get error with Compile him...

Anybody help me please?

PS--

PCI card is

Radeon 5770

Atheros AR5B91

Ethernet RTL8139

i post my DSDT and ioreg file here


Attached Files



#2
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



see with this see the airport



Attached File  DSDT.aml.zip   6.72KB   3 downloads





good hack



#3
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



see with this see the airport



attachicon.gifDSDT.aml.zip





good hack

thanks

jw002-350a-glasses-of-beer-under-blue-sk



#4
iFIRE

iFIRE

    InsanelyMacaholic

  • Banned
  • PipPipPipPipPipPipPipPipPipPipPip
  • 3,807 posts
  • Gender:Male
  • Location:Bcn-Spain

and this for HD5770 show like this: :P



           Device (GFX0)
                {
                    Name (_ADR, Zero)
                    Name (_SUN, One)
                    Method (_DSM, 4, NotSerialized)
                    {
                        Store (Package (0x0E)
                            {
                                "AAPL,slot-name",
                                Buffer (0x09)
                                {
                                    "PCIe-1"
                                },
                                "@0,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@1,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@2,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@3,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "model",
                                Buffer (0x13)
                                {
                                    "ATI Radeon HD 5770"
                                },
                                "hda-gfx",
                                Buffer (0x0A)
                                {
                                    "onboard-1"
                                }
                            }, Local0)
                        DTGP (Arg0, Arg1, Arg2, Arg3, RefOf (Local0))
                        Return (Local0)
                    }
                }
                Device (HDAU)
                {
                    Name (_ADR, One)
                    Method (_DSM, 4, NotSerialized)
                    {
                        Store (Package (0x02)
                            {
                                "hda-gfx",
                                Buffer (0x0A)
                                {
                                    "onboard-1"
                                }
                            }, Local0)
                        DTGP (Arg0, Arg1, Arg2, Arg3, RefOf (Local0))
                        Return (Local0)
                    }
                }
            }





#5
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



this one show also the ethernet



Attached File  DSDT.aml.zip   6.8KB   2 downloads



gonna see later the graphics



#6
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...



and this for HD5770 show like this: :P



           Device (GFX0)
                {
                    Name (_ADR, Zero)
                    Name (_SUN, One)
                    Method (_DSM, 4, NotSerialized)
                    {
                        Store (Package (0x0E)
                            {
                                "AAPL,slot-name",
                                Buffer (0x09)
                                {
                                    "PCIe-1"
                                },
                                "@0,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@1,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@2,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "@3,name",
                                Buffer (0x0D)
                                {
                                    "ATY,Vervet"
                                },
                                "model",
                                Buffer (0x13)
                                {
                                    "ATI Radeon HD 5770"
                                },
                                "hda-gfx",
                                Buffer (0x0A)
                                {
                                    "onboard-1"
                                }
                            }, Local0)
                        DTGP (Arg0, Arg1, Arg2, Arg3, RefOf (Local0))
                        Return (Local0)
                    }
                }
                Device (HDAU)
                {
                    Name (_ADR, One)
                    Method (_DSM, 4, NotSerialized)
                    {
                        Store (Package (0x02)
                            {
                                "hda-gfx",
                                Buffer (0x0A)
                                {
                                    "onboard-1"
                                }
                            }, Local0)
                        DTGP (Arg0, Arg1, Arg2, Arg3, RefOf (Local0))
                        Return (Local0)
                    }
                }
            }




Thaaanks people...



I LIKE MORE AND MORE THIS SITE :thumbsup_anim:



#7
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

Don't work at all :(



#8
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



what is not working ?



good hack



#9
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



what is not working ?



good hack

not show any PCI card on system profile



#10
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



send new ioreg with the dsdt..



good hack



#11
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



send new ioreg with the dsdt..



good hack

Maybe this info help you :wink_anim:

Ethernet card RTL8139 is installed on PCI2 slot

Atheros AR5B91 WiFi is installed on PCIEx1 slot

Radeon 5770 is on PCIEX16 slot

Attached Files



#12
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



only can see that in night .. i'm working without mac os x



good hack



#13
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



this ioreg is with my dsdt ?



i think not...



boot with my dsdt and get the ioreg



if this is with my dsdt.. really don't understand .. i apply in it new 2 devices and not showing in the dsdt



good hack



#14
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



this ioreg is with my dsdt ?



i think not...



boot with my dsdt and get the ioreg



if this is with my dsdt.. really don't understand .. i apply in it new 2 devices and not showing in the dsdt



good hack

now is OK,sorry :wink_anim:

Attached Files



#15
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



try with this one



Attached File  DSDT.aml.zip   6.89KB   1 downloads



if any problems send again ioreg booting with this dsdt



good hack



#16
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



try with this one



attachicon.gifDSDT.aml.zip



if any problems send again ioreg booting with this dsdt



good hack

thanks for your time... :rolleyes:

Again not show any PCI card :blush:

Attached Files



#17
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



try again with this one



Attached File  DSDT.aml.zip   6.06KB   4 downloads



good hack



#18
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



try again with this one



attachicon.gifDSDT.aml.zip



good hack

this one brok everything like wifi,video resolution,and all,im now boot from Backup and replace file :thumbsup_anim:



#19
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,549 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



only boot



DSDT=



man really don't know why this happen...  but that giga have a old dsdt.. maybe better forget all thing .. if works good .. like u say is only cosmetic





good hack



#20
HUSABER

HUSABER

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPip
  • 877 posts
  • Gender:Male
  • Location:Cyprus
  • Interests:HusabergFC-600 FourStroke,KTM500 TwoStroke,TM300 TwoStroke
    Free Time-My Hackintosh&Ap...

hello



only boot



DSDT=



man really don't know why this happen...  but that giga have a old dsdt.. maybe better forget all thing .. if works good .. like u say is only cosmetic





good hack

Yup only this is problem..cosmetics :hysterical:

Thanks again for your lossess time :thumbsup_anim:
