Lion on old laptop MSI‑GX700 (MS‑1719) motherboard

MSI‑GX700 MS‑1719 DSDT keyboard not working touchpad not working

  • Please log in to reply
7 replies to this topic

#1
max00r

max00r

    InsanelyMac Protégé

  • Members
  • Pip
  • 9 posts
  • Gender:Male
  • Location:Poland
Hi Guys,
i have working OS X 8.3. Not working keyboard, touch pad, sound kard, camera, WiFi and battery is not recognized.

Teh most important is keyboard and touch pad. Can you help me with my dsdt, or special kext for this machine?

I make my DSDT on linux with hackintosh-hardware-analyser-1.0.9.sh from this forum http://www.projectos...?showtopic=1341

This is LOG

MSI MS-1719x (reporting by hackintosh-hardware-analyser-1.0.9.sh)
Bios vers: 080014_ 03/11/2008
Intel(R) Core(TM)2 Duo CPU	 T7700 @ 2.40GHz	 2400 MHz CPU-model 15
=====================================================
Bus info		 Device	 Class	 Description
pci@0000:08:00.0			 display	 G84M [GeForce 8600M GT] [10DE:0407]
pci@0000:01:04.3			 storage	 Integrated MS/xD Controller [1217:7130]
pci@0000:00:1f.1 scsi0	 storage	 82801HM/HEM (ICH8M/ICH8M-E) IDE Controller [8086:2850]
pci@0000:00:1f.2 scsi2	 storage	 82801HM/HEM (ICH8M/ICH8M-E) SATA Controller [AHCI mode] [8086:2829]
usb@1:1		 scsi5	 storage
pci@0000:00:1b.0			 multimedia 82801H (ICH8 Family) HD Audio Controller [8086:284B]
pci@0000:06:00.0 wlan0	 network	 PRO/Wireless 4965 AG or AGN [Kedron] Network Connection [8086:4229]
pci@0000:07:00.0 eth0	 network	 RTL8111/8168 PCI Express Gigabit Ethernet controller [10EC:8168]
pci@0000:00:1a.0			 bus		 82801H (ICH8 Family) USB UHCI Controller #4 [8086:2834]
pci@0000:00:1a.1			 bus		 82801H (ICH8 Family) USB UHCI Controller #5 [8086:2835]
pci@0000:00:1a.7			 bus		 82801H (ICH8 Family) USB2 EHCI Controller #2 [8086:283A]
pci@0000:00:1d.0			 bus		 82801H (ICH8 Family) USB UHCI Controller #1 [8086:2830]
pci@0000:00:1d.1			 bus		 82801H (ICH8 Family) USB UHCI Controller #2 [8086:2831]
pci@0000:00:1d.2			 bus		 82801H (ICH8 Family) USB UHCI Controller #3 [8086:2832]
pci@0000:00:1d.7			 bus		 82801H (ICH8 Family) USB2 EHCI Controller #1 [8086:2836]
pci@0000:01:04.0			 bus		 Firewire (IEEE 1394) [1217:00F7]
pci@0000:00:1f.3			 bus		 82801H (ICH8 Family) SMBus Controller [8086:283E]
=====================================================
/proc/asound/oss/sndstat:0: ALC888 Analog (DUPLEX)
/proc/asound/oss/sndstat:0: Realtek ALC888
====================================================
Model: ATA TOSHIBA MK2546GS (scsi)
Disk /dev/sda: 250GB
Partition Table: msdos
Number Start End	 Size Type	 File system Flags
2	 32.3kB 96.4GB 96.4GB primary ntfs		 boot
3	 96.4GB 250GB 154GB extended			 lba
5	 96.4GB 118GB 22.0GB logical ntfs
6	 118GB 250GB 132GB logical ntfs

=====================================================
Socket Designation: DIMM0
Installed Size: 2048 MB (Double-bank Connection)
Socket Designation: DIMM2
Installed Size: 2048 MB (Double-bank Connection)
=====================================================

I attach DSDT.
Thanks a lot for help!
Sorry for my english. I'm too old to learn languages :-)

Attached Files



#2
3.14r2

3.14r2

    The Round One

  • Members
  • PipPipPipPipPipPipPipPip
  • 1,333 posts
  • Location:Molvania
For keyboard and touchpad you'd need PS/2 drivers.

Intel wireless cards ARE NOT supported in OS X (Apple doesn't use Intel WiFi cards). Therefore either buy an USB WiFi adapter or replace the card with compatible one from Atheros or Broardcom (not all Atheros/Broadcom cards are supported though - only certain models).

Sound should work either with VoodooHDA or patched original apple audio driver.

Battery support can be added via DSDT and/or additional driver.

If you want someone to edit your DSDT, please be sure to extract it in Linux/Windows and attach it to your post.

#3
max00r

max00r

    InsanelyMac Protégé

  • Members
  • Pip
  • 9 posts
  • Gender:Male
  • Location:Poland
Thanks for answer. I attach my DSDT file now.

Just i wrote first, i drop this dsdt on linux ;-)

I looking for an appleps2.kext but i lost it? Can someone may send me this ps2 driver for 10.8.3 lion?
Patched alc888 and battery kext too, or please help me fix my DSDT. I'll by very happy for this :-)

#4
3.14r2

3.14r2

    The Round One

  • Members
  • PipPipPipPipPipPipPipPip
  • 1,333 posts
  • Location:Molvania

I looking for an appleps2.kext but i lost it?

Try one of the fallowing
http://www.projectos...wtopic=1452&hl=
http://www.insanelym...h-intel-x3100/:

#5
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,466 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco
Hello

try this one

hdef set to alc888 maybe must use another layout ..

Attached File  DSDT.zip   7.88KB   15 downloads

test the native powermanagement

remove nullcpupowermanagement.kext

set in org.chameleon

generate p and c-states=Yes

good hack

#6
max00r

max00r

    InsanelyMac Protégé

  • Members
  • Pip
  • 9 posts
  • Gender:Male
  • Location:Poland
Thanks Guys.
i try new dsdt, and native powermanagment. Steel no audio, i use HDAenabler.No batery.
I'm trying ps2 controller from 3.14r2 links, but not working too. This laptop is {censored} :-)
Steel fighting, but got little headache now :-)

#7
Mr.Graphic

Mr.Graphic

    InsanelyMac Protégé

  • Members
  • Pip
  • 14 posts
  • Gender:Male
  • Location:EU
@max00r
My laptop MSIGX700. This laptop is not {censored} smoke.gif
I have not read enough.

My kexts:

NullCPUPowerManagement
AppleACPIBatteryManager
AppleACPIPS2Nub
ApplePS2Controller
AppleHDA
EvoReboot
FakeSMC

Attached Files



#8
max00r

max00r

    InsanelyMac Protégé

  • Members
  • Pip
  • 9 posts
  • Gender:Male
  • Location:Poland
Hello!
Thanks for kexts @Mr.Graphic!
I now, it's good motherboard, but my polish Aristo i375 notebook on this motherboard is {censored} :-)

Now Is better. I have working keyborad, and battery indicator working. But sound card not working, sleep not working. Touchpad not working.
May You send me your DSDT file too?

Thanks a lot!

regards
MAX
