#1
Crabhunter

Crabhunter

    InsanelyMac Sage

  • Members
  • PipPipPipPipPip
  • 254 posts
Hi, I'm working on a new laptop and I'm currently working on getting sound.
The laptop has an intel hm77 chipset and intel high definition audio.
I have tried all the voodoo kexts I can find and at best just get a crackling when a sound is played and at worst an unbootable system.
Any ideas where I go from here?
Mike

#2
Lejenk

Lejenk

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPipPipPip
  • 1,381 posts
  • Gender:Male
  • Location:Netherlands
Find out which sound chip you have. You probably need a patched AppleHDA and a DSDT edit to get sound working.
The easiest way would be extracting your codec from an Ubuntu Live usb. How to do this is described in the following post: http://www.insanelym...x/#entry1861876

All information regarding your audio can be found in codec.txt file.

#3
Crabhunter

Crabhunter

    InsanelyMac Sage

  • Members
  • PipPipPipPipPip
  • 254 posts
I just don't have that much time on my hands to work through that but thanks, it might be I have to.
Mike

#4
eep357

eep357

    Triple Platinum

  • Supervisors
  • 2,527 posts
  • Gender:Male
  • Location:Dark Side of The Wall
  • Interests:things and stuff
Or with IOregestryExplorer:

Attached File  Notification Center.jpg   106.18KB   102 downloads

Unless it needs to be sorta working for this part to show up.

#5
Crabhunter

Crabhunter

    InsanelyMac Sage

  • Members
  • PipPipPipPipPip
  • 254 posts
I've been to the acer website and I notice the driver they list for sound is realtek, I'm going to install that in windows and see if I can get any clues as to what I might need for osx i.e. alc 889.
Mike

#6
eep357

eep357

    Triple Platinum

  • Supervisors
  • 2,527 posts
  • Gender:Male
  • Location:Dark Side of The Wall
  • Interests:things and stuff
IOregistryExplorer is Mac app.

Attached Files



#7
Crabhunter

Crabhunter

    InsanelyMac Sage

  • Members
  • PipPipPipPipPip
  • 254 posts
Well no clues using ioregexplorer, I will just keep trying realtec kexts until hopefully one works.
Mike

hmm getting bored with randomly trying alc**** kexts, how can I tell in windows which it is, I can't find any clues in the device manager or by looking at the driver files.
Mike

#8
eep357

eep357

    Triple Platinum

  • Supervisors
  • 2,527 posts
  • Gender:Male
  • Location:Dark Side of The Wall
  • Interests:things and stuff
I don't really use Windows. IORegistryExplorer is a Hackintosher's best friend, so chances are you'll need to use it many times. Just launch it, and scroll down to the section that matches the picture. That's all

#9
Crabhunter

Crabhunter

    InsanelyMac Sage

  • Members
  • PipPipPipPipPip
  • 254 posts
OK that helped, I'm now looking for 269.
Sorry I thought it was just a general screenshot I didn't realise how helpful you were being.
Very grateful.
Mike

#10
Lejenk

Lejenk

    InsanelyMac Legend

  • Members
  • PipPipPipPipPipPipPipPipPip
  • 1,381 posts
  • Gender:Male
  • Location:Netherlands
Needs a DSDT edit though: http://www.insanelym...-inspiron-1464/

If you don't have a DSDT yet, here's a video explaining how to extract it from windows:
http://www.youtube.com/watch?v=wK8sHsQ-76Q

It will need patching, you can use DSDT Editor to do so, if you have trouble with it, leave the extracted DSDT here :)
