P45-UD3P CPU runs hot .help


  • Please log in to reply
42 replies to this topic

#1
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
Hello I installed with method Stella's V3 and all work OK .

But i noticed temperature in CPU is aproaching 59-62 ºC in my q6600 quad.

Please what the correct way to decrease temp? adding ketx NullCPUPower temp decrease 10-15ºC but i lost sleep... any way best alternative ?

Thanks

#2
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
use Chameleon RC5(Chameleon RC5 mode with mem detection enabled and automatic P-States & C-States generation for native power managment)

Look it
http://www.insanelym...howtopic=225766

Download Chameleon RC5
http://www.insanelym...howtopic=231075

if you need to apply patches (lpc, HPET) use DSDT EDITOR and PATCHER
http://www.insanelym...p...t&p=1501081
PATCHES
http://www.insanelym...p...t&p=1501094

Posted Image

#3
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, thanks for response, seems complicated method for me, can you explain best?

Have I make a new installation? i don't understand how create a dsdt for my Hackintosh is a

MOBO GIGABYTE GA P45-UD3P BIOS F8
CPU Q6600 QUAD
4GB RAM DDR2 800MHZ
NVIDIA GS8400

THANKS

#4
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
go into terminal
type
perl -e 'open(CMD, "ioreg -lw0 \| grep DSDT|") or die; while(<CMD>) { chomp; if($_ =~ /\"DSDT\.?\d?\"=<([^>]*)>/) { $buff = $1; open(PIP, "|xxd -r -p > dsdt.aml") or die; print PIP "$1"; } }'

the DSDT will be generated in user folder

send me

after

in terminal type kextstat
use pastebin
http://pastebin.com

#5
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
i sent a PM thanks

Here the link for my kextstat
My kextsat


Thanks for help

#6
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
this is not an original DSDT

or has a DSDT in your system
or do you use biosmod

Posted Image

#7
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, I 'm not in bios mod, I installed SnowLeopard with package Stella V3, i think it include a dsdt for this motherboard .

Can I modify this dsdt for reduce temperature of CPU and in the future update osx with no problems.??

Actually what is the best method for installing Snow Leopard in P45- UD3P and fully funcionality including correct temperature for CPU? I heard other package called KaKewalk

#8
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
I always do my manuals installations
so I know what I'm installing
avoiding problems

for native power managment and restart fix --> Chameleon RC5
http://www.insanelym...howtopic=231075

include in boot.plist

<key>DropSSDT</key>
<string>Yes</string>
<key>GeneratePStates</key>
<string>Yes</string>
<key>GenerateCStates</key>
<string>Yes</string>


DSDT

-DTGP - it's used by other patches
-AHCI SATA orange icon - Change ID of SATA device to fake ESB2 AHCI (silver icons for internal HDs instead of orange ones)
-Rename device AZAL to HDEF and change all references to it, apply ALC889A
-Remove IRQ from device PIC and move IRQs from devices RTC and TMR to device HPET
-Change the length of IO segment in device RTC to 0x02 (fix CMOS reset)
-Change method _PTS where Arg0 is 0x05 (shutdown)
-*Change methods _STA and _CRS into device HPET (to avoid AppleIntelCPUPowerManagement panic)
-*Change ID of device with _ADR 0x001F0000 (LPC)

KEXTs
fakesmc.kext, legacyhda.kext, *Jmicron

DSDT EDITOR
http://www.insanelym...p...t&p=1501081
PATCHES
http://www.insanelym...p...t&p=1501094

Posted Image

#9
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, ok can you make a guide for install? explain steps? in my snow leopard i have chamaleon RC4 ,
How I install RC5?

THanks

#10
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
the chameleon is .pkg http://www.insanelym...p...t&p=1543024
2 clicks and choose the location

*you can rely on a tutorial, this is in Portuguese (GA P35-DS3)
http://www.insanelym...howtopic=224874

use the search forum and find something more specific
if you prefer
*Installation is simple
on the "post install" that things change

after installing
use the Chameleon RC5 and the DSDT and EDITOR/PATCHER

----------------------

you do not need to format
you can extract an original dsdt and apply patches(on Windows[Everest], for example)
http://www.insanelym...howtopic=225991

send me your original DSDT

#11
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
OK, I download a Ubuntu live cd and extract my original dsdt.aml.

I will post my dsdt.aml soon as posible.
Thanks

#12
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, my original dsdt extract with ubuntu.

and my kextstat

My kextsat

Attached Files



#13
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
Attached File  dsdt.aml_xavifm.zip   6.92KB   9 downloads

DTGP
AHCI SATA(orange icon)
ALC889A
HPET
IRQs
Shutdown
LPC

add in your boot.plist

<key>GeneratePStates</key>
<string>Yes</string>
<key>GenerateCStates</key>
<string>Yes</string>

delete OpenHaltRestart.kext <-- Fix restart -> ChameleonRC5 / Fix Shutdown -> DSDT
Disabler <-- what does this kext disable?
fakesmc --> always we need that

#14
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, the dsdt.aml is modified with c-states or p-states to my processor q6600?

What's kext's adicionals i have to install?

Have i remove nullpowermanagement kext and sleepenabler kext?

thanks

#15
Gringo Vermelho

Gringo Vermelho

    The Jan Bird fix

  • Supervisors
  • 6,224 posts
  • Gender:Male
  • Location:Brazil

hello, the dsdt.aml is modified with c-states or p-states to my processor q6600?

Attached File  Muppet.jpg   46.36KB   9 downloads
After all Mal has done to help you the least you can do is read his posts.

for native power managment and restart fix --> Chameleon RC5
http://www.insanelym...howtopic=231075

include in boot.plist

<key>DropSSDT</key>
<string>Yes</string>
<key>GeneratePStates</key>
<string>Yes</string>
<key>GenerateCStates</key>
<string>Yes</string>

Have i remove nullpowermanagement kext

Yes, delete it.

#16
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
sorry my english is not good and most of post i understand very good . thanks

#17
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
hello, I instaled chamaleon RC5 and add strings to boot.plist. and overwrite my dsdt.aml in folder /extra.

temperature of CPU cores maintain in about 45-51º in idle. it's OK?

I deleted ketxt's nullpowermanagement and sleep enabler.

But now when system goes to sleep , when return to this state system reboot instead of return to desktop.

Any solution?

Thanks

#18
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs

hello, I instaled chamaleon RC5 and add strings to boot.plist. and overwrite my dsdt.aml in folder /extra.

temperature of CPU cores maintain in about 45-51º in idle. it's OK?

Posted Image Yep
can improve
but so is much better

I deleted ketxt's nullpowermanagement and sleep enabler.
But now when system goes to sleep , when return to this state system reboot instead of return to desktop.
Any solution?
Thanks


s3 is set in the bios?

System preferences is that?
Posted Image

Posted Image

#19
xavifm

xavifm

    InsanelyMac Protégé

  • Members
  • PipPip
  • 52 posts
Hello, yes s3 is active in bios, and system preferences is ok , ready for sleep.

Can you tell me which ketxts i have to delete with this modified dsdt? sleep problem is relationed with dsdt?

Thanks

#20
MaLd0n

MaLd0n

    ...filling veins with juice of chaos...

  • Moderators
  • 16,017 posts
  • Gender:Male
  • Location:Rio de Janeiro
  • Interests:HacksLikeMacs
"extensions.mkext" you have one?
If the answer is YES...delete

send me a new kextstat
and
kextstat | grep -v com.apple
